GH-H650
Specifications
GH-H650 Series Electro-Optical Characteristics:
| Code for parts GH-XXXXX |
Lighting Color |
Material | VF（V） | λ（nm） | lv（m cd） | Viewing angle at 50% lv | Lens color | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Typ | Max | λᴅ | λᴘ | △λ | Min | Typ | |||||
| RVH650TR-DPJ |  |
AlGalnP | 2.0 | 2.5 | 630 | 640 | 18 | 8800 | 12000 | 6 | Water transparent |
| OVH650TR-CSB |  |
AlGalnP | 2.0 | 2.5 | 625 | 635 | 18 | 18000 | 32000 | 6 | Water transparent |
| YUH650TR-CSB |  |
AlGalnP | 2.0 | 2.5 | 590 | 595 | 20 | 18000 | 32000 | 6 | Water transparent |
| GBH650TR-DPJ |  |
AlGalnP | 2.0 | 2.5 | 570 | 572 | 16 | 1600 | 2900 | 6 | Water transparent |
| G5H650TR-6PD |  |
lnGaN | 3.3 | 3.7 | 520 | 515 | 35 | 14200 | 24000 | 6 | Water transparent |
| BPH650TR-HP3 |  |
lnGaN | 3.1 | 3.7 | 470 | 465 | 25 | 4000 | 8650 | 6 | Water transparent |
| W6H650TR-HP3 |  |
lnGaN | 3.1 | 3.7 | x=0.22~0.38 Y=0.22~0.36 |
320 | 470 | 170 | Yellow | ||
All information and data in this website are subject to change without prior notice.
Description
