GH-S151
Specifications
GH-S151 Series Electro-Optical Characteristics:
| Part Number Example |
Reverse dark current (nA) |
Reverse breakdown voltage (V) |
Open circuit voltage (mV) |
Short circuit current (μA) |
Reverse light current(μA) |
|||
|---|---|---|---|---|---|---|---|---|
| Typ | Min | Typ | Min | Typ | Min | Typ | Typ | |
| DLS151BS-40E | 8 | 33 | 170 | 250 | 410 | 5 | 7 | 6 |
| DLS151TS-40E | 8 | 33 | 170 | 250 | 410 | 5 | 7 | 7 |
All information and data in this website are subject to change without prior notice.
